♦ General Weighing: Zero and Tare functions for convenient weighing operations.
♦ Hold Functions: Peak Hold, Hold, and Auto-Hold for stable and easy-to-read weight values.
♦ Animal Weighing: Dedicated animal weighing function for dynamic weighing applications.
♦ Battery Monitoring: Battery capacity indication for easy power-level monitoring.
♦ Power Saving: Automatic power-off and power-saving functions to extend battery life.
♦ RS232 Communication: Optional RS232 interface for communication with external devices.
♦ Real-Time Clock: Optional real-time clock function

• Display: LED
• Resolution: 5,000e
• A/D Conversion: 10 SPS
• Load Signal Range: −7 to 12.8 mV
• Excitation Voltage: +3.3 VDC
• Weight Unit: kg
• Interval: 1 / 2 / 5 / 10 / 20 / 50
• Load Cells: Up to 4 × 350 Ω
• Load Cell Type: 4-wire or 6-wire load cells
• Battery: 3.7 V / 2 Ah Lithium
• Battery Life: Approx. 25 hours
• Operating Temperature: −10°C to +40°C
• Relative Humidity: ≤85% RH

♦ Connections
• Load Cell Connection:
Supports up to 4 × 350 Ω load cells
Compatible with 4-wire and 6-wire load cells
Quick connector or standard plug connection

• RS232 Communication Interface
- Pin 2: TXD
- Pin 3: RXD
- Pin 5: GND

♦ Platform sizes:
- 30 x 40 cm
- 40 x 50 cm
- 50 x 60 cm
- 60 x 70 cm
- 60 x 80 cm
- 100 x 100 cm
- 125 x 125 cm
- 150 x 150 cm
- Contact us for any other desired size.
